GIGABYTE B660M GAMING X Motherboard

The GIGABYTE B660M GAMING X is a compact Micro-ATX gaming motherboard designed for Intel LGA1700 desktop processors. It uses the Intel B660 Express chipset and supports Intel Core 14th, 13th and 12th Generation processors, as well as compatible Pentium Gold and Celeron processors. The motherboard features four DDR5 DIMM slots supporting up to 256GB of system memory in dual-channel configuration. It supports DDR5 memory speeds up to 5600 MT/s through overclocking and Intel XMP memory profiles. For graphics and expansion, the B660M GAMING X provides a PCIe 4.0 x16 slot and an additional PCIe 4.0 x4 slot. Storage connectivity includes two PCIe 4.0 x4 M.2 connectors with M.2 Thermal Guard, along with four SATA 6Gb/s ports. Networking is provided by a fast 2.5GbE LAN controller with bandwidth management. The standard B660M GAMING X does not include integrated Wi-Fi or Bluetooth. The Wi-Fi version is sold separately as the B660M GAMING X AX. The board uses an 8+1+1 phase Hybrid Digital VRM design with DrMOS, a 6-layer 2X copper PCB and fully covered thermal design. It also includes Smart Fan 6, RGB Fusion 2.0, Q-Flash Plus and a pre-installed I/O shield.
